PWR-IE170W-PC-DC

The PWR-IE170W-PC-DC is a power supply module designed for Cisco Industrial Ethernet (IE) Series switches. It is specifically designed to provide reliable and efficient power delivery in industrial environments where DC power sources are commonly used.

The PWR-IE170W-PC-DC power supply module has a maximum power output of 170 watts and operates on DC power input. It is compatible with a wide range of DC power sources commonly found in industrial settings, making it suitable for deployment in various industrial applications.

This power supply module is designed to withstand harsh environmental conditions, including temperature extremes, electrical noise, and vibration, ensuring reliable operation in demanding industrial environments. It features ruggedized construction and enhanced protection mechanisms to safeguard against power fluctuations and voltage spikes.

The PWR-IE170W-PC-DC module is hot-swappable, allowing for easy installation or replacement without interrupting the switch operation. It offers power management capabilities, including power monitoring and control features, to help optimize power usage and ensure efficient operation of the network infrastructure.

In summary, the PWR-IE170W-PC-DC power supply module is designed to provide reliable and efficient power delivery for Cisco Industrial Ethernet (IE) Series switches in DC-powered industrial environments. It offers ruggedized construction, protection mechanisms, and power management capabilities to support reliable and stable network operations in challenging industrial settings.

• Primary Information

  Product Description:	Cisco DC-DC Power Module for POE solution – power converter – 170 Watt
  Device Type:	Power converter – DIN rail mountable
  Weight:	3.68 lbs
  Input Voltage:	10.8 – 60 V
  Output Voltage:	54 V
  Power Capacity:	170 Watt
  Dimensions (WxDxH):	5.9 in x 4.5 in x 5.7 in
  Designed For:	Industrial Ethernet 4000 Series

• General

  Device Type:

  Power converter – DIN rail mountable

• Power Device

  Input Voltage:	10.8 – 60 V
  Output Voltage:	54 V
  Max Electric Current:	3.15 A
  Power Capacity:	170 Watt

• Environmental Parameters

  Min Operating Temperature:	-40 °F
  Max Operating Temperature:	140 °F
  Humidity Range Operating:	10 – 95% (non-condensing)

• Dimensions & Weight

  Width:	5.9 in
  Depth:	4.5 in
  Height:	5.7 in
  Weight:	3.68 lbs

• Compatibility Information

  Designed For:

  Cisco Industrial Ethernet 4000 Series
