The HPE Networking Instant On Access Points AP22D is an SMB-focused Wi-Fi Certified 6 access point that provides reliable wired and wireless connectivity over a 2.5GbE uplink port with a minimal device footprint. This access point can reduce device clutter while powering downlink devices such as IP Phones or receipt printers with 2x 15W of PoE(802.3af) and supporting 75+ wireless devices over 802.11ax Wi-Fi 6 with an aggregate wireless throughput of 1.7Gbps. Easily manage the Instant On AP22D with the Instant On mobile app or portal to create guest and employee networks, govern access control lists, and set POE schedules to customize power use. Make the most of your limited space in your small business by mounting the Instant On AP22D to a desk or wall with included mounting kits.
- Wi-Fi Certified 6 wireless access point, with 2.5GbE uplink port
- 2.5GbE uplink port provides up to 2x more bandwidth than 1GbE ports without the need for new Cat5/6(a) cables to be installed
- Four 1GbE downlink ports that supply up to 2x 15W of PoE (802.3af)
- Up to 1.7Gbps aggregate wireless throughput
- Features Orthogonal Frequency-Division Multiple Access (OFDMA) which allows access points to handle multiple Wi-Fi 6 capable clients on each channel simultaneously and improve efficiency by boosting overall capacity, reducing latency.
- WARRANTY: Aruba Instant On 2-year* warranty includes unlimited chat support, 24/7 phone support for the first 90 days, and community support for as long as you own the product
Specifications | |
---|---|
Certifications | Wi-Fi Certified 6 |
Input voltage | Class 4 or 6 PoE (802.3at or bt) |
Wi-Fi Antenna | Dual Omni-directional 2×2 MIMO |
Connectivity standards | Not specified |
Ports | 1x 2.5GbE uplink and 4x 1GbE downlink |
Mounting | Built-in Wall mount or included desk mount |
Power consumption | 51W (PoE) or 50W (DC) |
Warranty | 2-year hardware warranty, 90-day phone and chat install support |
Dimensions (imperial) | 3.39 x 5.91 x 1.85 inches |
Weight | .79 lbs |
Aruba Instant On WiFi 6 Comparison
AP21 | AP22 | AP22D | AP25 | AP32 | |
---|---|---|---|---|---|
Ideal deployment |
SOHOs, conference rooms, studio retail, low-density areas |
Boutique hotels, independent restaurants, medical offices, schools |
SOHOs, reception areas, retail shops |
Gaming, high-traffic areas, professional offices |
High device density, offices, tech start-ups, multi-purpose facility |
Recommended number of devices |
50 | 75 | 75 | 100+ | 100 |
Data rate | 1.2 Gbps (5Ghz) 300 Mbps (2.4Ghz) |
1.2 Gbps (5Ghz) 574 Mbps (2.4Ghz) |
1.2 Gbps (5Ghz) 574 Mbps (2.4Ghz) 900 Mbps switching capacity |
4.8 Gbps (5Ghz) 574 Mbps (2.4Ghz) |
2.4 Gbps (6Ghz) 1.2 Gbps (5Ghz) 300 Mbps (2.4Ghz) |
Antennas | Dual-band 802.11ax 2x2 5Ghz/2.4Ghz MIMO |
Dual-band 802.11ax 2x2 5Ghz/2.4Ghz MIMO |
Dual-band 802.11ax 2x2 5Ghz/2.4Ghz MIMO |
Dual-band 802.11ax 4x4 5Ghz MU-MIMO 2x2 2.4Ghz MU-MIMO |
Tri-band 802.11ax 2x2 6Ghz/5Ghz/2.4Ghz MIMO |
Physical specifications |
145mm x 145mm x 51mm Weight: 255g |
160mm x 160mm x 37mm Weight: 500g |
86mm x 150mm x 47mm Weight: 360g |
200mm x 200mm x 45mm Weight: 775g |
160mm x 160mm x 39mm Weight: 520g |
Power | PoE In: 802.3at 11.0 W (POE) 10.9W (DC) |
PoE In: 802.3af 10.1W (POE) 8.8W (DC) |
PoE In: 802.3at/802.3bt 51W (POE) 50W (DC) |
PoE In: 802.3at 20,1W (POE) 15.9W (DC) |
PoE In: 802.3at 12.9 (PoE) 11.0W (DC) |
