Cisco NIM-ES2-4 – Expansion module – Gigabit Ethernet x 4 – for Cisco 4451-X

The NIM-ES2-4 is a Network Interface Module (NIM) designed for Cisco ISR G2 and ISR 4000 Series routers. It provides additional Ethernet connectivity options and expands the capabilities of the router.

The NIM-ES2-4 module offers four Gigabit Ethernet ports, allowing for the connection of multiple devices or networks. Each port supports high-speed data transmission up to 1 Gbps, providing fast and reliable network connectivity.

This module is hot-swappable, which means it can be inserted or removed from the router without disrupting the network operation. It simplifies the installation and maintenance process by allowing for easy module replacement or upgrades.

Overall, the NIM-ES2-4 is a versatile network interface module that enhances the connectivity options of Cisco ISR G2 and ISR 4000 Series routers. With its multiple Gigabit Ethernet ports and support for advanced features, it provides flexibility, scalability, and improved network performance.

• Primary Information

  Product Description:	Cisco Network Interface Module – expansion module – Gigabit Ethernet x 4
  Device Type:	Expansion module
  Form Factor:	Plug-in module
  Ports:	Gigabit Ethernet x 4
  Cabling Type:	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
  Data Link Protocol:	10Mb LAN, 100Mb LAN, GigE
  Data Transfer Rate:	1 Gbps
  Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
  System Requirements:	Cisco IOS XE 3.15S
  Designed For:	Cisco 4451-X, 4451-X Application Experience, 4451-X Integrated Services Router, 4451-X Integrated Services Router Security Bundle, 4451-X Integrated Services Router Voice and Video Bundle, 4451-X Integrated Services Router Voice Security Bundle

• General

  Device Type:	Expansion module
  Form Factor:	Plug-in module

• Networking

  Ports:	Gigabit Ethernet x 4
  Connectivity Technology:	Wired
  Cabling Type:	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
  Data Link Protocol:	Ethernet, Fast Ethernet, Gigabit Ethernet
  Data Transfer Rate:	1 Gbps
  Features:	Full duplex capability, layer 2 switching, auto-negotiation, half duplex mode
  Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

• Expansion / Connectivity

  Interfaces:

  4 x 1000Base-T – RJ-45

• Software / System Requirements

  OS Required:

  Cisco IOS XE 3.15S

• Compatibility Information

  Designed For:

  Cisco 4451-X, 4451-X Application Experience, 4451-X Integrated Services Router, 4451-X Integrated Services Router Security Bundle, 4451-X Integrated Services Router Voice and Video Bundle, 4451-X Integrated Services Router Voice Security Bundle
