Cisco PWR-IE65W-PC-DC – DC Power Module for POE solution – Power converter (DIN rail mountable) – 18 – 60 V – 65 Watt – for Industrial Ethernet 3000 Series

The PWR-IE65W-PC-DC is a power supply module designed for Cisco Industrial Ethernet (IE) Series switches. It is specifically designed to provide reliable power delivery in industrial environments where DC power sources are commonly used.

The PWR-IE65W-PC-DC power supply module has a maximum power output of 65 watts and operates on DC power input. It is compact in size and designed to be easily installed in space-constrained industrial environments.

This power supply module is built to withstand harsh environmental conditions, including temperature extremes, electrical noise, and vibration, ensuring reliable operation in demanding industrial settings. It features enhanced protection mechanisms to safeguard against power fluctuations and voltage spikes, ensuring the stability and longevity of the network infrastructure.

The PWR-IE65W-PC-DC module is hot-swappable, allowing for easy installation or replacement without interrupting the switch operation. It offers power management capabilities, including power monitoring and control features, to help optimize power usage and ensure efficient operation of the network.

In summary, the PWR-IE65W-PC-DC power supply module is designed to provide reliable power delivery for Cisco Industrial Ethernet (IE) Series switches in DC-powered industrial environments. With its compact size, rugged construction, and power management capabilities, it offers a dependable solution for powering industrial networks and ensuring the stability and performance of critical industrial applications.

• Primary Information

  Product Description:	Cisco DC-DC Power Module for POE solution – power converter – 65 Watt
  Device Type:	Power converter – DIN rail mountable
  Weight:	1.19 lbs
  Input Voltage:	18 – 60 V
  Output Voltage:	54 V
  Power Capacity:	65 Watt
  Dimensions (WxDxH):	2.6 in x 4.6 in x 5.9 in
  Designed For:	Industrial Ethernet 3000 Series

• General

  Device Type:

  Power converter – DIN rail mountable

• Power Device

  Input Voltage:	18 – 60 V
  Output Voltage:	54 V
  Max Electric Current:	1.2 A
  Power Capacity:	65 Watt

• Environmental Parameters

  Min Operating Temperature:	-40 °F
  Max Operating Temperature:	140 °F
  Humidity Range Operating:	10 – 95% (non-condensing)

• Dimensions & Weight

  Width:	2.6 in
  Depth:	4.6 in
  Height:	5.9 in
  Weight:	1.19 lbs

• Compatibility Information

  Designed For:

  Cisco Industrial Ethernet 3000 Series
