About the IE-4000-4S8P4G-E
SFP and PoE+ ports sit side by side on the IE-4000-4S8P4G-E: four 100M SFP ports and eight 100M PoE+ ports, plus four 1G combo uplinks. Each uplink is SFP or RJ-45, with one of each pair active. It mounts on DIN rail and forwards at line rate on all ports and all packet sizes.
The PoE budget is 125 W maximum and depends on the power supply fitted. Input is redundant DC, nominally 9.6 to 60 VDC, and the DIN-rail supplies that fit, such as the PWR-IE170W-PC-AC and PWR-IE240W-PCAC-L, are listed below. The IE-3500-8P3S-E is a newer model.
Management is through the Cisco IOS CLI or Web Device Manager. It runs from -40 to +70°C in a vented enclosure and from -40 to +60°C in a sealed one, and it meets EN 50155 for railway use and DNV GL for ships and high speed and light craft.
What’s included
- IE-4000-4S8P4G-E switch
Sold separately
- A DIN-rail power supply, such as the PWR-IE170W-PC-AC
- SFP transceivers for the four 100M SFP ports and any uplinks you run as SFP
Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.
IE-4000-4S8P4G-E specifications
| Downlink ports | 4× FE SFP + 8× FE PoE+ |
|---|---|
| Uplink ports | 4× GE combo (SFP or RJ45), one of each pair active |
| PoE budget | 125 W maximum (depends on the power supply fitted) |
| Forwarding rate | Line rate on all ports and all packet sizes |
| Power supply | Redundant DC input, nominal 9.6 to 60 VDC; DIN-rail power supplies |
| Form factor | DIN-rail; 6.12 × 6.12 × 5.09 in (155.4 × 155.4 × 129.2 mm); 6.35 lb (2.88 kg) |
| Management | Cisco IOS CLI; Web Device Manager |
| Operating temperature | -40 to +70°C (vented enclosure); -40 to +60°C (sealed enclosure); -34 to +75°C (fan or blower-equipped enclosure) |
Full specifications (6)
Industrial certifications
| Hazardous locations | ANSI/ISA 12.12.01; CSA C22.2 No. 213; IECEx and ATEX (60079-0, -15) Class I, Zone 2; cabinet enclosure required |
|---|---|
| Substation | IEEE 1613; IEC 61850-3 (KEMA) |
| Railway | EN 50155; EN 50121-4; EN 50121-3-2 |
| Traffic and rail signalling | NEMA TS-2 |
| Marine | DNV GL (ships, high speed and light craft) |
| Ingress protection | IP30 |
Compare IE4000 models
Swipe the table sideways to see every column.
| Model | Ports | PoE budget | Price |
|---|---|---|---|
| IE-4000-4S8P4G-E this page | 4× FE SFP + 8× FE PoE+ | 125 W | $1,585.00 |
| IE-4000-16GT4G-E | 16× GE copper | None | $3,995.00 · In stock |
| IE-4000-4GC4GP4G-E | 4× GE combo (SFP or RJ45) + 4× GE PoE+ | 125 W | $2,350.00 · In stock |
| IE-4000-4T4P4G-E | 4× FE copper + 4× FE PoE+ | 125 W | $2,450.00 |
| IE-4000-8GS4G-E | 8× GE SFP | None | $3,650.00 · In stock |
| IE-4000-8GT4G-E | 8× GE copper | None | $3,772.87 |
| IE-4000-8S4G-E | 8× FE SFP | None | $2,251.00 |
Compatible parts
| Power supplies | ||
|---|---|---|
| PWR-IE50W-AC-L | 50 W AC, no PoE | $395.00 · In stock |
| PWR-IE50W-AC= | 50 W AC, no PoE | $390.00 · In stock |
| PWR-IE65W-PC-AC= | 65 W AC, PoE-capable | $240.00 |
| PWR-IE65W-PC-DC | 65 W DC, PoE-capable | $524.63 · In stock |
| PWR-IE170W-PC-AC | 170 W AC, PoE-capable | $695.00 · In stock |
| PWR-IE170W-PC-DC | 170 W DC, PoE-capable | $838.33 |
| PWR-IE240W-PCAC-L | 240 W AC, PoE-capable | $1,095.00 |
| PWR-IE480W-PCAC-L | 480 W AC, PoE-capable | $1,985.99 · In stock |
| Rack mount kits | ||
| STK-RACK-DINRAIL | 19 in. DIN rail mount kit | $225.00 · In stock |
| SD card | ||
| SD-IE-1GB= | spare SD card | Ask for a quote |
Newer model: IE-3500-8P3S-E. Ask us for a quote on it.
Common questions
How much PoE does the IE-4000-4S8P4G-E deliver?
The PoE budget is 125 W maximum and depends on the power supply fitted. The eight 100M copper ports are the PoE+ ports.
Which ports on the IE-4000-4S8P4G-E are 1G?
The four combo uplinks are 1G, SFP or RJ-45. The four SFP ports and eight PoE+ ports on the downlink side are 100M.
