Cisco IE-4000-4GC4GP4G-E – Industrial Ethernet 4000 Series – Switch – managed – 8 x combo Gigabit SFP + 4 x 10/100/1000 (PoE+) – DIN rail mountable – PoE+ – DC power

IE-4000-4GC4GP4G-E Industrial Ethernet 4000 Series Switch: Rugged Reliability for Demanding Environments

The Cisco IE-4000-4GC4GP4G-E Industrial Ethernet 4000 Series Switch, specifically the IE-4000-4GC4GP4G-E model, is a powerful and versatile switch designed for harsh industrial environments. Here’s what it offers:

• Built to Last: Engineered to withstand extreme temperatures, vibration, shock, and noise, ensuring reliable operation in factories, power plants, and other industrial settings.
• High-Performance Connectivity: Delivers Gigabit Ethernet connectivity with PoE+ support, ideal for powering devices like IP phones, security cameras, and wireless access points.
• Advanced Networking Features: VLANs segment your network for enhanced security and manageability.

Benefits:

• Improved Network Performance: Gigabit speeds and PoE+ support enable efficient data transfer and power delivery for your industrial devices.
• Enhanced Security: Network segmentation through VLANs helps isolate critical data and improve overall network security.
• Increased Reliability: Rugged design and redundant features minimize downtime and ensure uninterrupted operation..

Overall, the Cisco Industrial Ethernet 4000 Series Switch (CISCO IE-4000-4GC4GP4G-E) is a powerful solution for building reliable and secure industrial networks. It’s ideal for businesses that need high-performance connectivity, robust features, and easy management in harsh environments.

• Primary Information

  Product Description:	Cisco Industrial Ethernet 4000 Series – switch – 12 ports – managed
  Device Type:	Switch – 12 ports – managed
  Subtype:	Gigabit Ethernet
  Ports:	8 x combo Gigabit SFP + 4 x 10/100/1000 (PoE+)
  Power Over Ethernet (PoE):	PoE+
  Capacity:	Virtual interfaces (VLANs): 1000 ¦ IGMP groups: 1000
  MAC Address Table Size:	16K entries
  Routing Protocol:	Static IPv4 routing
  Remote Management Protocol:	SNMP 1, SNMP 2, RMON 2, RMON, Telnet, SNMP 3, HTTP, SSH, CLI
  Features:	NAT support, BOOTP support, trunking, VLAN support, IGMP snooping, Syslog support, DiffServ support, MAC address filtering, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), Bidirectional Forwarding Detection (BFD), Uni-Directional Link Detection (UDLD), DHCP relay, Port Security, MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NTP time synchronization, Class of Service (CoS), Precision Time Protocol (PTP), IGMP filtering, PROFINET v2, IP source guard, Flex Link support, Resilient Ethernet Protocol (REP), SmartPort technology, Parallel Redundancy Protocol (PRP)
  Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 1588v2, IEEE 1613
  Power:	DC 9.6 – 60 V 4.3 A
  Dimensions (WxDxH):	6.1 in x 5.1 in x 6.1 in
  Weight:	6.35 lbs

• General

  Device Type:	Switch – 12 ports – managed
  Enclosure Type:	DIN rail mountable
  Subtype:	Gigabit Ethernet
  Ports:	8 x combo Gigabit SFP + 4 x 10/100/1000 (PoE+)
  Power Over Ethernet (PoE):	PoE+
  Capacity:	Virtual interfaces (VLANs): 1000 ¦ IGMP groups: 1000
  MAC Address Table Size:	16K entries
  Routing Protocol:	Static IPv4 routing
  Remote Management Protocol:	SNMP 1, SNMP 2, RMON 2, RMON, Telnet, SNMP 3, HTTP, SSH, CLI
  Authentication Method:	RADIUS, TACACS+
  Features:	NAT support, BOOTP support, trunking, VLAN support, IGMP snooping, Syslog support, DiffServ support, MAC address filtering, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), Bidirectional Forwarding Detection (BFD), Uni-Directional Link Detection (UDLD), DHCP relay, Port Security, MAC Address Notification, Remote Switch Port Analyzer (RSPAN), NTP time synchronization, Class of Service (CoS), Precision Time Protocol (PTP), IGMP filtering, PROFINET v2, IP source guard, Flex Link support, Resilient Ethernet Protocol (REP), SmartPort technology, Parallel Redundancy Protocol (PRP)
  Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 1588v2, IEEE 1613
  RAM:	512 MB
  Flash Memory:	128 MB

• Expansion / Connectivity

  Interfaces:	4 x 1000Base-T RJ-45 PoE+ ¦ 4 x 1000Base-T RJ-45 uplink ¦ 4 x SFP uplink ¦ 1 x mini-USB Type B ¦ 1 x console RJ-45 ¦ 4 x 1000Base-X SFP ¦ 4 x 1000Base-T RJ-45
  Expansion Slots:	1 (total) / 0 (free) x SD Memory Card

• Power

  Voltage Required:	DC 9.6 – 60 V
  Electric Current Required:	4.3 A
  Power Consumption Operational:	40 Watt

• Miscellaneous

  Included Accessories:	1 GB SD card
  MTBF:	550,940 hours
  Compliant Standards:	CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN55024, EN55022 Class A, CB, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-11, RoHS, EN 61000-4-8, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, UL 508, IEC 60529 IP30, CSA 22.2 No. 142, EN 61131-2, IEC 60068-2-64, EN 61000-4-9, EN 61000-4-29, EN50155, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-52, IEC 60068-2-60, EN 50121-4, NOM-019-SCFI-1998, VCCI Class A, KN22, China RoHS, EN 50121-3-2, EN 61326, IEC 61163, CISPR 11 class A, EN 61000-4-18, IEC 61850-3, IEC/UL/CSA/EN 60950-1, IEC 60068-2-3, EN 61373, ISO 9223

• Software / System Requirements

  Software Included:

  Cisco IOS LAN Base

• Dimensions & Weight

  Width:	6.1 in
  Depth:	5.1 in
  Height:	6.1 in
  Weight:	6.35 lbs

• Environmental Parameters

  Min Operating Temperature:	-40 °F
  Max Operating Temperature:	167 °F
  Humidity Range Operating:	5 – 95% (non-condensing)
  Min Storage Temperature:	-40 °F
  Max Storage Temperature:	185 °F
