Cisco C9300-48T-E Catalyst 9300 Switch – 48x 1G, Modular Uplinks, Network Essentials
$2,855.98List price: $11,240.82
In stock (4) Ships today if ordered by 3 PM ET
Buying in volume or need it refurbished? Ask for a quote. Or call (984) 225-1600.
About the C9300-48T-E
The C9300-48T-E has 48 copper ports at 10/100/1000 and no PoE, in a 1U Catalyst 9300 running Cisco IOS XE with the Network Essentials software tier. The C9300-48T-A is the same switch with Network Advantage.
It comes with a 350 W supply and takes a second for redundancy. It switches 256 Gbps and forwards 190.47 Mpps. If some ports need to power phones or access points, the C9300-48P-E is the PoE+ version.
There are no built-in uplinks. Add a network module, from four 1G SFP ports to two 40G QSFP ports, and stack up to eight switches over StackWise-480 at 480 Gbps.
What’s included
- C9300-48T-E switch with 48 copper 1G ports and the Network Essentials software tier
- 350 W AC power supply (PWR-C1-350WAC-P)
Sold separately
- A network module for uplinks; all five options are under Compatible parts below
- A second power supply for redundancy
- StackWise cables (STACK-T1-50CM, STACK-T1-1M or STACK-T1-3M)
Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.
C9300-48T-E specifications
| Downlink ports | 48× 10/100/1000, data only |
|---|---|
| Uplink ports | Modular: optional network module (4× 1G SFP, 4× 10G/mGig copper, 8× 10G/1G SFP+, 2× 40G QSFP or 2× 25G/10G/1G SFP28); none included by default |
| PoE budget | None (data-only model) |
| Stacking | StackWise-480, 480 Gbps; up to 8 members |
| Switching capacity | 256 Gbps |
| Forwarding rate | 190.47 Mpps |
| Power supply | 350 W AC PWR-C1-350WAC-P included; second supply optional for redundancy/PoE |
| Form factor | 1U rack-mount; 1.73 × 17.5 × 17.7 in (4.4 × 44.5 × 44.9 cm) (H × W × D) with default power supply |
| Management | Cisco IOS XE (CLI, WebUI) |
| Feature tier | Network Essentials |
| Weight | 16.43 lb (7.45 kg) |
Other versions of this model
- C9300-48T-A Network Advantage$4,149.00
Compare Catalyst 9300 models
Swipe the table sideways to see every column.
| Model | Ports | PoE budget | Price |
|---|---|---|---|
| C9300-48T-E this page | 48× 10/100/1000, data only | None | $2,855.98 · In stock |
| C9300-24T-E | 24× 10/100/1000, data only | None | $3,225.00 · In stock |
| C9300-24P-E | 24× 10/100/1000 PoE+ | 445 W | $2,769.42 · In stock |
| C9300-24U-E | 24× 10/100/1000 UPOE | 830 W | $4,422.64 · In stock |
| C9300-24UX-E | 24× 100M/1G/2.5G/5G/10G multigigabit UPOE | 560 W | $7,750.00 · In stock |
| C9300-48P-E | 48× 10/100/1000 PoE+ | 437 W | $3,490.72 · In stock |
| C9300-48U-E | 48× 10/100/1000 UPOE | 822 W | $7,178.10 |
| C9300-48UXM-E | 36× 100M/1G/2.5G + 12× 100M/1G/2.5G/5G/10G multigigabit, all UPOE | 490 W | $6,005.00 |
| C9300-24S-E | 24× 1G SFP | None | $12,941.44 · In stock |
| C9300-48S-E | 48× 1G SFP | None | $18,500.00 · In stock |
| C9300-24UB-E | 24× 10/100/1000 UPOE (higher-scale model) | 830 W | Ask for a quote |
| C9300-24H-E | 24× 10/100/1000 UPOE+ | 830 W | Ask for a quote |
| C9300-24UXB-E | 24× 100M/1G/2.5G/5G/10G multigigabit UPOE (higher-scale model) | 560 W | Ask for a quote |
| C9300-48UB-E | 48× 10/100/1000 UPOE (higher-scale model) | 822 W | Ask for a quote |
| C9300-48H-E | 48× 10/100/1000 UPOE+ | 822 W | Ask for a quote |
| C9300-48UN-E | 48× 100M/1G/2.5G/5G multigigabit UPOE | 645 W | Ask for a quote |
Compatible parts
| Network modules | ||
|---|---|---|
| C9300-NM-4G= | 4× 1G SFP | $475.61 · In stock |
| C9300-NM-4M | 4× 100M/1G/2.5G/5G/10G multigigabit copper | $580.00 · In stock |
| C9300-NM-8X= | 8× 10G/1G SFP+ | $885.00 · In stock |
| C9300-NM-2Y | 2× 25G/10G/1G SFP28 | $1,352.38 |
| C9300-NM-2Q | 2× 40G QSFP | $750.00 · In stock |
| Power supplies | ||
| PWR-C1-350WAC-P | 350 W AC power supply | $334.24 · In stock |
| PWR-C1-715WAC-P | 715 W AC power supply | $595.00 · In stock |
| PWR-C1-715WDC | 715 W DC power supply | $375.00 |
| PWR-C1-1100WAC-P | 1100 W AC power supply | $650.00 |
| PWR-C1-1900WAC-P | 1900 W AC power supply | $1,314.00 |
| Stack cables | ||
| STACK-T1-50CM | Data stack cable, 50 cm | $50.54 |
| STACK-T1-1M | Data stack cable, 1 m | $101.08 |
| STACK-T1-3M | Data stack cable, 3 m | $151.62 |
| StackPower cables | ||
| CAB-SPWR-30CM | StackPower cable, 30 cm | $48.02 |
| CAB-SPWR-150CM | StackPower cable, 150 cm | $50.54 |
| Fans | ||
| FAN-T2= | Fan | Ask for a quote |
Common questions
Is the C9300-48T-E the same as the C9300-48T-A?
Same hardware, different software tier: Network Essentials on the C9300-48T-E, Network Advantage on the C9300-48T-A.
What uplinks can the C9300-48T-E have?
Whatever network module you add: 4x 1G SFP, 4x 10G mGig copper, 8x 10G SFP+, 2x 40G QSFP or 2x 25G SFP28.
