Cisco IE-2000-4S-TS-G-L IE2000 Industrial Switch – 4x 100M SFP, 2x 1G SFP, LAN Lite
$480.00List price: $1,276.00
In stock (8) Ships today if ordered by 3 PM ET
Buying in volume or need it refurbished? Ask for a quote. Or call (984) 225-1600.
About the IE-2000-4S-TS-G-L
SFP is the only port type on the IE-2000-4S-TS-G-L, with four 100 Mbps SFP downlinks and two 1G SFP uplinks. Series maximums are up to 7.6 Gbps of switching capacity and up to 5.66 Mpps with 64-byte packets, line rate at all packet sizes. Its feature tier is LAN Lite.
The DIN-rail body measures 5.1 in high, 3.15 in wide and 4.51 in deep and weighs 2.69 lb (1.22 kg). DC input comes from a DIN-rail power supply, with options from 50 W to 480 W, such as the PWR-IE50W-AC= or PWR-IE240W-PCAC-L in the list below.
It meets IEEE 1613 and IEC 61850-3 for substations, EN 50155 for railway use and NEMA TS-2 for traffic and rail signaling, with DNV for marine use and IP30 ingress protection. The IE-3100-8T4S-E is its newer model.
What’s included
- IE-2000-4S-TS-G-L switch
Sold separately
- A DIN-rail power supply, such as the PWR-IE50W-AC=
- SFP transceivers for all four downlinks and both uplinks
- The STK-RACK-DINRAIL 19 in. DIN rail mount kit
Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.
IE-2000-4S-TS-G-L specifications
| Downlink ports | 4× 100 Mbps SFP (FE) |
|---|---|
| Uplink ports | 2× Gigabit SFP |
| Switching capacity | Up to 7.6 Gbps (series maximum) |
| Forwarding rate | Up to 5.66 Mpps with 64-byte packets, line rate at all packet sizes (series maximum) |
| Power supply | DC input; DIN-rail power supplies (50 W to 480 W options) |
| Form factor | DIN-rail mount; 5.1"H x 3.15"W x 4.51"D in (130mm H x 80mm W x 115mm D); 2.69 lb (1.22 kg) |
| Management | Cisco IOS CLI; Web Device Manager; Express Setup |
| Feature tier | LAN Lite |
| Operating temperature | -40 to +70°C (vented enclosure, 40 LFM); -40 to +60°C (sealed enclosure); -34 to +75°C (fan or blower-equipped enclosure, 200 LFM) |
Full specifications (6)
Industrial certifications
| Hazardous locations | ANSI/ISA 12.12.01 Class 1, Div 2 A-D; ATEX (EN 60079-0, -15) Class 1, Zone 2 A-D; cabinet enclosure required |
|---|---|
| Substation | IEEE 1613; IEC 61850-3 (KEMA) |
| Railway | EN 50155; EN 50121-3-2; EN 50121-4 |
| Traffic and rail signalling | NEMA TS-2 |
| Marine | DNV |
| Ingress protection | IP30 |
Compare IE2000 models
Swipe the table sideways to see every column.
| Model | Ports | Uplinks | PoE budget | Software tier | Price |
|---|---|---|---|---|---|
| IE-2000-4S-TS-G-L this page | 4× 100 Mbps SFP (FE) | 2× Gigabit SFP | LAN Lite | $480.00 · In stock | |
| IE-2000-16PTC-G-E | 16× 10/100 Fast Ethernet copper (4 of them PoE/PoE+) | 2× Gigabit combo (SFP or RJ45) | 4× PoE/PoE+ ports | LAN Base | $2,250.00 · In stock |
| IE-2000-16PTC-G-L | 16× 10/100 Fast Ethernet copper (4 of them PoE/PoE+) | 2× Gigabit combo (SFP or RJ45) | 4× PoE/PoE+ ports | LAN Lite | $3,304.84 |
| IE-2000-16PTC-G-NX | 16× 10/100 Fast Ethernet copper (4 of them PoE/PoE+) | 2× Gigabit combo (SFP or RJ45) | 4× PoE/PoE+ ports | Enhanced LAN Base | $2,740.00 · In stock |
| IE-2000-16TC-B | 16× 10/100 Fast Ethernet copper | 2× FE combo (SFP or RJ45) + 2× FE SFP | None | LAN Base | $2,775.00 · In stock |
| IE-2000-16TC-G-E | 16× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) + 2× FE SFP | None | LAN Base | $2,150.00 · In stock |
| IE-2000-16TC-G-L | 16× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) + 2× FE SFP | None | LAN Lite | $1,995.00 |
| IE-2000-16TC-G-N | 16× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) + 2× FE SFP | None | Enhanced LAN Base | $2,410.00 |
| IE-2000-16TC-G-X | 16× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) + 2× FE SFP | None | LAN Base | $2,796.37 |
| IE-2000-16TC-L | 16× 10/100 Fast Ethernet copper | 2× FE combo (SFP or RJ45) + 2× FE SFP | None | LAN Lite | $1,775.00 · In stock |
| IE-2000-4S-TS-G-B | 4× 100 Mbps SFP (FE) | 2× Gigabit SFP | LAN Base | $995.00 | |
| IE-2000-4T-B | 6× 10/100 Fast Ethernet copper | None separate (all six ports copper) | LAN Base | $879.00 | |
| IE-2000-4T-G-B | 4× 10/100 Fast Ethernet copper | 2× Gigabit copper | LAN Base | $990.25 | |
| IE-2000-4T-G-L | 4× 10/100 Fast Ethernet copper | 2× Gigabit copper | LAN Lite | $946.11 | |
| IE-2000-4T-L | 6× 10/100 Fast Ethernet copper | None separate (all six ports copper) | LAN Lite | $831.05 | |
| IE-2000-4TS-B | 4× 10/100 Fast Ethernet copper | 2× 100 Mbps SFP (FE) | LAN Base | $789.37 | |
| IE-2000-4TS-G-B | 4× 10/100 Fast Ethernet copper | 2× Gigabit SFP | LAN Base | $890.39 | |
| IE-2000-4TS-G-L | 4× 10/100 Fast Ethernet copper | 2× Gigabit SFP | LAN Lite | $929.00 | |
| IE-2000-4TS-L | 4× 10/100 Fast Ethernet copper | 2× 100 Mbps SFP (FE) | LAN Lite | $865.66 | |
| IE-2000-8TC-B | 8× 10/100 Fast Ethernet copper | 2× FE combo (SFP or RJ45) | None | LAN Base | $1,250.00 |
| IE-2000-8TC-G-B | 8× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) | None | LAN Base | $1,645.21 · In stock |
| IE-2000-8TC-G-E | 8× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) | None | LAN Base | $2,050.00 |
| IE-2000-8TC-G-L | 8× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) | None | LAN Lite | $1,348.82 |
| IE-2000-8TC-G-N | 8× 10/100 Fast Ethernet copper | 2× Gigabit combo (SFP or RJ45) | None | Enhanced LAN Base | $1,860.83 |
| IE-2000-8TC-L | 8× 10/100 Fast Ethernet copper | 2× FE combo (SFP or RJ45) | None | LAN Lite | $1,701.20 · In stock |
Compatible parts
| Power supplies | ||
|---|---|---|
| PWR-IE50W-AC-L | 50 W AC, no PoE | $395.00 · In stock |
| PWR-IE50W-AC= | 50 W, no PoE | $390.00 · In stock |
| PWR-IE65W-PC-AC= | 65 W, PoE-capable | $240.00 |
| PWR-IE65W-PC-DC | 65 W DC, PoE-capable | $524.63 · In stock |
| PWR-IE170W-PC-AC | 170 W, PoE-capable | $695.00 · In stock |
| PWR-IE170W-PC-DC | 170 W DC, PoE-capable | $838.33 |
| PWR-IE240W-PCAC-L | 240 W, PoE-capable | $1,095.00 |
| PWR-IE480W-PCAC-L | 480 W, PoE-capable | $1,985.99 · In stock |
| Rack mount kits | ||
| STK-RACK-DINRAIL | 19 in. DIN rail mount kit | $225.00 · In stock |
| SD card | ||
| SD-IE-1GB= | ruggedized SD memory card | Ask for a quote |
Newer model: IE-3100-8T4S-E. Ask us for a quote on it.
Common questions
Does the IE-2000-4S-TS-G-L have any RJ-45 ports?
Its downlinks and uplinks are all SFP: four at 100 Mbps and two at 1G.
What speed are the IE-2000-4S-TS-G-L downlinks?
All four are 100 Mbps SFP. The two uplinks are 1G SFP.
Is the IE-2000-4S-TS-G-L approved for marine use?
It carries DNV, and its ingress protection is IP30.
