Cisco IE-2000-8TC-B IE2000 Industrial Switch – 8x 100M, 2x 100M Combo, LAN Base

About the IE-2000-8TC-B

The IE-2000-8TC-B pairs eight 10/100 Fast Ethernet copper downlinks with two FE combo uplinks, each one SFP or RJ45. You manage it through the Cisco IOS CLI, Web Device Manager or Express Setup. This model runs LAN Base.

It takes DC input from a DIN-rail power supply, with options from 50 W to 480 W. The PWR-IE50W-AC-L and PWR-IE480W-PCAC-L are two of the supplies in its list below.

It runs from -40 to +70°C in a vented enclosure with 40 LFM of airflow and from -40 to +60°C in a sealed one. It meets IEEE 1613 and IEC 61850-3 for substations and EN 50155 for railway use. The IE-3100-8T2C-E is the newer model.

What’s included

• IE-2000-8TC-B switch

Sold separately

• A DIN-rail power supply, such as the PWR-IE50W-AC-L
• SFP transceivers, if you use the SFP side of the combo uplinks

Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.

IE-2000-8TC-B specifications

Downlink ports	8× 10/100 Fast Ethernet copper
Uplink ports	2× FE combo (SFP or RJ45)
Switching capacity	Up to 7.6 Gbps (series maximum)
Forwarding rate	Up to 5.66 Mpps with 64-byte packets, line rate at all packet sizes (series maximum)
Power supply	DC input; DIN-rail power supplies (50 W to 480 W options)
Management	Cisco IOS CLI; Web Device Manager; Express Setup
Feature tier	LAN Base
PoE budget	None (no PoE ports)
Operating temperature	-40 to +70°C (vented enclosure, 40 LFM); -40 to +60°C (sealed enclosure); -34 to +75°C (fan or blower-equipped enclosure, 200 LFM)

Full specifications (6)

Industrial certifications

Hazardous locations	ANSI/ISA 12.12.01 Class 1, Div 2 A-D; ATEX (EN 60079-0, -15) Class 1, Zone 2 A-D; cabinet enclosure required
Substation	IEEE 1613; IEC 61850-3 (KEMA)
Railway	EN 50155; EN 50121-3-2; EN 50121-4
Traffic and rail signalling	NEMA TS-2
Marine	DNV
Ingress protection	IP30

Compare IE2000 models

Swipe the table sideways to see every column.

Model	Ports	Uplinks	PoE budget	Software tier	Price
IE-2000-8TC-B this page	8× 10/100 Fast Ethernet copper	2× FE combo (SFP or RJ45)	None	LAN Base	$1,250.00
IE-2000-16PTC-G-E	16× 10/100 Fast Ethernet copper (4 of them PoE/PoE+)	2× Gigabit combo (SFP or RJ45)	4× PoE/PoE+ ports	LAN Base	$2,250.00 · In stock
IE-2000-16PTC-G-L	16× 10/100 Fast Ethernet copper (4 of them PoE/PoE+)	2× Gigabit combo (SFP or RJ45)	4× PoE/PoE+ ports	LAN Lite	$3,304.84
IE-2000-16PTC-G-NX	16× 10/100 Fast Ethernet copper (4 of them PoE/PoE+)	2× Gigabit combo (SFP or RJ45)	4× PoE/PoE+ ports	Enhanced LAN Base	$2,740.00 · In stock
IE-2000-16TC-B	16× 10/100 Fast Ethernet copper	2× FE combo (SFP or RJ45) + 2× FE SFP	None	LAN Base	$2,775.00 · In stock
IE-2000-16TC-G-E	16× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45) + 2× FE SFP	None	LAN Base	$2,150.00 · In stock
IE-2000-16TC-G-L	16× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45) + 2× FE SFP	None	LAN Lite	$1,995.00
IE-2000-16TC-G-N	16× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45) + 2× FE SFP	None	Enhanced LAN Base	$2,410.00
IE-2000-16TC-G-X	16× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45) + 2× FE SFP	None	LAN Base	$2,796.37
IE-2000-16TC-L	16× 10/100 Fast Ethernet copper	2× FE combo (SFP or RJ45) + 2× FE SFP	None	LAN Lite	$1,775.00 · In stock
IE-2000-4S-TS-G-B	4× 100 Mbps SFP (FE)	2× Gigabit SFP		LAN Base	$995.00
IE-2000-4S-TS-G-L	4× 100 Mbps SFP (FE)	2× Gigabit SFP		LAN Lite	$480.00 · In stock
IE-2000-4T-B	6× 10/100 Fast Ethernet copper	None separate (all six ports copper)		LAN Base	$879.00
IE-2000-4T-G-B	4× 10/100 Fast Ethernet copper	2× Gigabit copper		LAN Base	$990.25
IE-2000-4T-G-L	4× 10/100 Fast Ethernet copper	2× Gigabit copper		LAN Lite	$946.11
IE-2000-4T-L	6× 10/100 Fast Ethernet copper	None separate (all six ports copper)		LAN Lite	$831.05
IE-2000-4TS-B	4× 10/100 Fast Ethernet copper	2× 100 Mbps SFP (FE)		LAN Base	$789.37
IE-2000-4TS-G-B	4× 10/100 Fast Ethernet copper	2× Gigabit SFP		LAN Base	$890.39
IE-2000-4TS-G-L	4× 10/100 Fast Ethernet copper	2× Gigabit SFP		LAN Lite	$929.00
IE-2000-4TS-L	4× 10/100 Fast Ethernet copper	2× 100 Mbps SFP (FE)		LAN Lite	$865.66
IE-2000-8TC-G-B	8× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45)	None	LAN Base	$1,645.21 · In stock
IE-2000-8TC-G-E	8× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45)	None	LAN Base	$2,050.00
IE-2000-8TC-G-L	8× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45)	None	LAN Lite	$1,348.82
IE-2000-8TC-G-N	8× 10/100 Fast Ethernet copper	2× Gigabit combo (SFP or RJ45)	None	Enhanced LAN Base	$1,860.83
IE-2000-8TC-L	8× 10/100 Fast Ethernet copper	2× FE combo (SFP or RJ45)	None	LAN Lite	$1,701.20 · In stock

Compatible parts

Power supplies
PWR-IE50W-AC-L	50 W AC, no PoE	$395.00 · In stock
PWR-IE50W-AC=	50 W, no PoE	$390.00 · In stock
PWR-IE65W-PC-AC=	65 W, PoE-capable	$240.00
PWR-IE65W-PC-DC	65 W DC, PoE-capable	$524.63 · In stock
PWR-IE170W-PC-AC	170 W, PoE-capable	$695.00 · In stock
PWR-IE170W-PC-DC	170 W DC, PoE-capable	$838.33
PWR-IE240W-PCAC-L	240 W, PoE-capable	$1,095.00
PWR-IE480W-PCAC-L	480 W, PoE-capable	$1,985.99 · In stock
Rack mount kits
STK-RACK-DINRAIL	19 in. DIN rail mount kit	$225.00 · In stock
SD card
SD-IE-1GB=	ruggedized SD memory card	Ask for a quote

Newer model: IE-3100-8T2C-E. Ask us for a quote on it.

Common questions

What are the uplinks on the IE-2000-8TC-B?

Two FE combo ports. Each one is SFP or RJ45.

What power does the IE-2000-8TC-B take?

DC input, from a DIN-rail power supply. The options run from 50 W to 480 W.
