About the NFX250-S2
The NFX250-S2 is the largest NFX250: a 6-core x86 processor, 32 GB of memory and a 400 GB SSD behind 8 RJ-45 ports, 2 SFP ports, 2 SFP+ ports and 2 RJ-45 uplinks. It runs Junos OS and is rated for 64 Gbps.
A single supply with a 140 W maximum AC draw powers it, with front-to-back airflow. Optics are sold separately.
What’s included
- NFX250 platform with 8 RJ-45, 2 SFP, 2 SFP+ and 2 RJ-45 uplink ports and a 6-core x86 processor
- 32 GB of memory and a 400 GB SSD
- Junos OS
Sold separately
- Optics for the pluggable ports
- Advanced licenses and Juniper Care, listed in Support & Licensing above
Choosing a version
- NFX250-S2 (this page): AC power, front-to-back airflow
Related models: NFX250-S1, NFX250-S1E.
Not sure which version you need? Call (984) 225-1600 or request a quote and we’ll check it against your rack and network.
NFX250-S2 specifications
| Network ports | 8x RJ-45, 2x SFP, 2x SFP+, 2x RJ-45 uplink |
|---|---|
| Throughput | 64 Gbps |
| Form factor | 1U, fixed chassis |
| Dimensions (H x W x D) | 1.72 x 17.36 x 12 in (4.4 x 44.1 x 30.5 cm) |
| Weight (as shipped) | 9.4 lb / 4.26 kg |
| Airflow | Front-to-back |
| Power supplies | 1 |
| Max power draw (AC) | 140 W |
| CPU | 1.9 GHz 6-core Intel |
| Memory | 32 GB |
| Storage | 400 GB SSD |
| MAC addresses (thousands) | 16 |
| Operating temperature | 32° through 122° F / 0° through 50° C |
| Operating system | Junos OS |
Full specifications (51)
Network ports
| RJ-45 Ports | 8 |
|---|---|
| SFP Ports | 2 |
| SFP+ Ports | 2 |
Management and other ports
| Console Ports | 2 |
|---|---|
| Console Port Type | RJ-45, Mini USB Type B |
| Management Ports | 1 |
| Management Port Type | RJ-45 |
| USB Ports | 1 |
| USB Port Type | Type A |
| Uplink Ports | 2 |
| Uplink Port Type | RJ-45 |
Chassis
| Chassis type | Fixed |
|---|---|
| Form Factor | 1U |
| Chassis Height | 1.72 in / 4.3688 cm |
| Chassis Width | 17.36 in / 44.0944 cm |
| Chassis Depth | 12 in / 30.48 cm |
| Chassis depth (with power supplies and fans) | 12 in / 30.48 cm |
| Weight (as shipped) | 9.4 lb / 4.26 kg |
Power
| Power supplies | 1 |
|---|---|
| Power supply airflow | Front-to-back |
| AC Max Power Consumption | 140 W |
Cooling
| Airflow Direction | Front-to-back |
|---|
Processor
| CPU | 1.9 GHz 6-core Intel |
|---|---|
| Memory (DRAM) | 32 GB |
Storage
| Internal Storage Size | 400 GB |
|---|---|
| Internal Storage Type | SSD |
Security performance
| IPsec | 1.2 Gbps |
|---|---|
| Managed Secure Router | 4 Gbps |
| Managed Security | 4 Gbps |
Performance
| Hardware Queues Per Port | 8 |
|---|
Switching and routing scale
| Throughput | 64 Gbps |
|---|---|
| MSTP Instances | 64 |
| MAC Addresses Per System (thousands) | 16 |
| Maximum Mirroring Sessions | 1 |
| Traffic Mirroring Destination VLANs | 1 |
| Traffic Mirroring Destination Ports | 1 |
| VLAN IDs | 4096 |
| VNF Capacity | 20 Gbps |
| VNFs (max) | 8 |
| Jumbo Frame | 9216 bytes |
Encryption
| IPsec Authentication Algorithms | MD5, SHA-1, SHA-128, SHA-256 |
|---|---|
| IPsec Encryption Algorithms | DES, 3DES, AES-256, AES-GCM |
Environmental
| Operating Temperature | 32° through 122° F / 0° through 50° C |
|---|---|
| Storage Temperature | -40° through 158° F / -40° through 70° C |
| Operating Altitude | 10000 ft (3048 m) |
| Humidity, operating (noncondensing) | 5% through 90% |
| Humidity, non-operating (noncondensing) | 5% through 90% |
| Seismic Tolerance | Zone 4 |
| Acoustic Noise Level (Max) | 50 dB |
| Maintenance Clearance | 30 in / 76.2 cm |
Software
| Operating system | Junos OS |
|---|
Common questions
How much memory does the S2 have?
32 GB, double the 16 GB on the NFX250-S1 and S1E.
How large is the SSD?
It ships with a 400 GB SSD, the largest of the NFX250 versions.
Does the S2 have more ports than the S1?
No. The ports are the same across the NFX250 versions.
