Juniper SRX300-SYS-JB Firewall with Junos Base Software

Name: Juniper SRX300-SYS-JB Firewall with Junos Base Software
Brand: Juniper
SKU: SRX300-SYS-JB
Price: 1329.90 USD
Availability: InStock

$1,329.90List price: $3,100.00

Juniper Care & licenses for this modelSee options ↓

A branch firewall and routing bundle with six Gigabit RJ-45 ports, two Gigabit SFP ports and Junos Software Base. The external supply and cable are included; the rack kit is separate.

In stock (10+) Ships in 1–2 business days

ConditionNew

WarrantyManufacturer

ShippingFree (US)

ReturnsRMA required · See policy

SKU: SRX300-SYS-JB Categories: Juniper, Security

Support & Licensing for the SRX300-SYS-JB

The SRX300-SYS-JB comes with Junos software for firewall, NAT, IPsec VPN, routing and switching. Most buyers add Juniper Care support; security subscriptions add threat protection such as IPS, antivirus and web filtering. Not sure what you need? Call (984) 225-1600 or request a quote and we'll spec it with you.

1Juniper Care support recommended

A support contract from Juniper for the SRX300-SYS-JB. Every level includes 24/7 tech support and software updates; they differ in how fast a failed part is replaced.

Core24/7 Juniper tech support (JTAC) and software updates. No hardware replacement.SVC-COR-SRX300JB
$206 / yr
Core PlusCore, plus repair or replacement shipped within 10 business days of Juniper receiving the failed part.SVC-CP-SRX300JB
$314 / yr
Next DayCore, plus a replacement part delivered the next business day (RMA issued by 3 p.m. local time).SVC-ND-SRX300JB
$327 / yr
Same DayCore, plus a replacement part delivered within 4 hours, 24/7.SVC-SD-SRX300JB
$435 / yr

More levels: onsite technician and 2-hour delivery

Next Day OnsiteNext Day delivery, plus a technician on site to install the replacement part.SVC-NDCE-SRX300JB
$380 / yr
Same Day OnsiteSame Day delivery, plus a technician on site to install the replacement part.SVC-SDCE-SRX300JB
$510 / yr
Same Day 2-HourCore, plus a replacement part delivered within 2 hours, 24/7.SVC-SD2-SRX300JB
$564 / yr

Delivery times depend on your location. Onsite technicians handle hardware replacement; software questions go to JTAC.

2Security subscription optional

Optional threat protection for the SRX300-SYS-JB, sold as 1, 3 or 5-year subscriptions. Licenses are per firewall.

Junos software

Included with the firewall

Firewall and NAT
IPsec VPN
Routing, MPLS and switching

Included

Advanced 1

Adds:

IPS (intrusion prevention)
App+ application security: identify, control and prioritize apps
SD-WAN application routing
SecIntel threat intelligence feeds

Subscription Includes Juniper software supportS-SRX300-A1-1/3/5

1 yr$209 3 yr$417$139 / yr 5 yr$626$125 / yr

Advanced 2

Everything in Advanced 1, plus:

Antivirus
Enhanced web filtering
Antispam

Subscription Includes Juniper software supportS-SRX300-A2-1/3/5

1 yr$645 3 yr$1,290$430 / yr 5 yr$1,935$387 / yr

Premium 1

Everything in Advanced 1, plus:

Juniper ATP Cloud: detects and blocks zero-day malware

Subscription Includes Juniper software supportS-SRX300-P1-1/3/5

1 yr$395 3 yr$790$263 / yr 5 yr$1,185$237 / yr

3Add-on licenses only if you need them

Remote access VPN (Juniper Secure Connect)VPN for remote users with the Juniper Secure Connect client, licensed by the number of users connected at once.
- 5 usersS-RA3-5CCU-S-1/3/5
  1 yr$67 3 yr$134$45 / yr 5 yr$201$40 / yr
- 25 users, SRX300 packS-RA3-SRX300-S-1/3/5
  1 yr$185 3 yr$371$124 / yr 5 yr$556$111 / yr
- 25 usersS-RA3-25CCU-S-1/3/5
  1 yr$286 3 yr$571$190 / yr 5 yr$856$171 / yr
Mist WAN AssuranceManage and monitor this firewall from the Juniper Mist cloud, with AI insights and service-level tracking.S-WAN-C1-1/3/5
1 yr$283 3 yr$567$189 / yr 5 yr$849$170 / yr
Mist WAN Assurance, Standard bundleWAN Assurance plus application visibility (Junos AppID, activated from Mist).S-SRX-S-C1-1/3/5
1 yr$393 3 yr$782$261 / yr 5 yr$1,171$234 / yr
Bundled with Juniper Care
- With Core supportS-SRX-S-C1-1/3/5-COR
  1 yr$444 3 yr$939$313 / yr 5 yr$1,433$287 / yr
- With Core Plus supportS-SRX-S-C1-1/3/5-CP
  1 yr$486 3 yr$1,066$355 / yr 5 yr$1,640$328 / yr
- With Next Day supportS-SRX-S-C1-1/3/5-ND
  1 yr$490 3 yr$1,078$359 / yr 5 yr$1,662$332 / yr
- With Same Day supportS-SRX-S-C1-1/3/5-SD
  1 yr$532 3 yr$1,197$399 / yr 5 yr$1,860$372 / yr
Mist WAN Assurance, Advanced bundleThe Standard bundle plus Marvis, Juniper's AI assistant for troubleshooting.S-SRX-A-C1-1/3/5
1 yr$524 3 yr$1,044$348 / yr 5 yr$1,565$313 / yr
Bundled with Juniper Care
- With Core supportS-SRX-A-C1-1/3/5-COR
  1 yr$574 3 yr$1,200$400 / yr 5 yr$1,826$365 / yr
- With Core Plus supportS-SRX-A-C1-1/3/5-CP
  1 yr$617 3 yr$1,327$442 / yr 5 yr$2,034$407 / yr
- With Next Day supportS-SRX-A-C1-1/3/5-ND
  1 yr$621 3 yr$1,340$447 / yr 5 yr$2,055$411 / yr
- With Same Day supportS-SRX-A-C1-1/3/5-SD
  1 yr$663 3 yr$1,458$486 / yr 5 yr$2,254$451 / yr
IPS signature updatesIntrusion prevention signature updates on their own. Every security subscription tier includes IPS.SRX300-IPS-1/3/5
1 yr$309 3 yr$841$280 / yr 5 yr$1,373$275 / yr
Enhanced web filteringWeb filtering on its own. The Advanced 2 tier includes it.SRX300-W-EWF-1/3/5
1 yr$309 3 yr$841$280 / yr 5 yr$1,373$275 / yr
ATP threat feedsJuniper ATP Cloud threat intelligence feeds only, with no file scanning. The Premium tiers include full ATP Cloud.SRX300-THRTFEED-1/3/5
1 yr$85 3 yr$172$57 / yr 5 yr$342$68 / yr

Description

About the SRX300-SYS-JB

The SRX300-SYS-JB combines the branch services gateway hardware with Junos Software Base under one part number. It provides six Gigabit RJ-45 ports and two Gigabit SFP ports. The included software covers firewall, NAT, IPsec, routing, MPLS and switching; an external supply and cable are included, with the rack kit ordered separately.

What’s included

SRX300-SYS-JB services gateway with six RJ-45 ports and two SFP ports
External power supply and power cable
Junos Software Base: firewall, NAT, IPsec, routing, MPLS and switching

Sold separately

Rack-mount kit
Advanced and Premium licenses and Juniper Care, listed in Support & Licensing above

Choosing a version

SRX300-SYS-JB (this page): Junos Software Base bundle, convection cooling airflow
SRX300: hardware only; JSB or JSE required, convection cooling airflow
SRX300-SYS-JB-T: Junos Software Base bundle, convection cooling airflow, TAA-compliant
SRX300-SYS-JE: Junos Software Enhanced bundle, convection cooling airflow

Related models: SRX320, SRX340.

Not sure which version you need? Call (984) 225-1600 or request a quote and we’ll check it against your rack and network.

SRX300-SYS-JB specifications

Network ports	6x RJ-45, 2x SFP
MACsec	Yes
Firewall throughput (1518B)	1900 Mbps
Firewall throughput (IMIX)	600 Mbps
IPsec VPN throughput (IMIX)	0.116 Gbps
Concurrent sessions (thousands)	64
Form factor	Desktop, fixed chassis
Dimensions (H x W x D)	1.38 x 12.64 x 7.60 in (3.5 x 32.1 x 19.3 cm)
Weight (as shipped)	4.38 lb / 1.99 kg
Airflow	Convection cooling
Power supplies	1
Memory	4 GB
Storage	8 GB Flash
MAC addresses (thousands)	15
Operating temperature	-4° through 140° F / -20° through 60° C
Operating system	Junos OS

Full specifications (63)

Network ports

RJ-45 Ports	6
SFP Ports	2
SFP Port MACsec	Yes

Management and other ports

Console Ports	2
Console Port Type	RJ-45, Mini USB Type B
USB Ports	1
USB Port Type	USB 3.0 Type A

Chassis

Chassis type	Fixed
Form Factor	Desktop
Chassis Height	1.38 in / 3.505 cm
Chassis Width	12.64 in / 32.106 cm
Chassis Depth	7.60 in / 19.304 cm
Chassis depth (with power supplies and fans)	7.60 in / 19.304 cm
Weight (as shipped)	4.38 lb / 1.99 kg
Weight (fully loaded)	4.38 lb / 1.99 kg

Power

Power supplies	1
Power Adapter Type	AC to DC
AC PSU Average Heat Dissipation	85 BTU/h
System Average Power Consumption	24.9 W
System Maximum DC Input Rating	2.8 A
System Maximum Current Rating	1 A
Maximum Current Consumption	0.346 A
Maximum Inrush Current	7 A (220 VAC)

Cooling

Airflow Direction	Convection cooling

Processor

Memory (DRAM)	4 GB

Storage

Internal Storage Size	8 GB
Internal Storage Type	Flash

Security performance

Firewall Throughput (1518B)	1900 Mbps
Firewall Throughput (64B)	200 Kpps
Firewall Throughput (IMIX)	600 Mbps
IPsec VPN Throughput (1400B)	0.336 Gbps
IPsec VPN Throughput (IMIX)	0.116 Gbps
Routing With Packet Mode (64B)	300 Kpps
Routing With Packet Mode (1518B)	1500 Mbps
Routing With Packet Mode (IMIX)	800 Mbps
NGFW Performance (CPS)	0.226 Gbps
Secure Web Access Firewall (CPS)	0.171 Gbps
AppID Sessions (thousands)	16
Application Visibility And Control	0.5 Gbps
GRE Tunnels	256
IPS Sessions (thousands)	16
Maximum SSL VPN Concurrent Users	25
Maximum Security Policies	1000
Maximum Security Zones	16
Maximum Virtual Routers	32
NAT Rules	1000
Recommended IPS	0.2 Gbps
URLF Sessions (thousands)	16

Performance

Route Table Size (RIB) (IPv4) (thousands)	256
Route Table Size (FIB) (IPv4) (thousands)	256
Route Table Size (RIB) (IPv6) (thousands)	256
Route Table Size (FIB) (IPv6) (thousands)	256
Max Concurrent Sessions (IPv4/IPv6) (thousands)	64
IPsec VPN Tunnels	256

Switching and routing scale

MAC Addresses Per System (thousands)	15
VLAN IDs	1000

Environmental

Operating Temperature	-4° through 140° F / -20° through 60° C
Storage Temperature	-4° through 158° F / -20° through 70° C
Operating Altitude	10000 ft / 3048 m
Humidity, operating (noncondensing)	10% through 90%
Humidity, non-operating (noncondensing)	5% through 95%
Maintenance Clearance	24 in / 60.96 cm

Software

Operating system	Junos OS

Common questions

What is in the software bundle?

It pairs an external power supply and 6x RJ-45 and 2x SFP with Junos Software Base (firewall, NAT, IPsec, routing, MPLS and switching).

What about the rack-mount kit?

It is not included. Order the rack-mount kit separately for the SRX300.

What does the Base bundle cover?

Junos Software Base covers firewall, NAT, IPsec, routing, MPLS and switching with the included hardware.
