Juniper ACX5448-M-DC-AFI Router, 44x 10GE + 6x 100GE, MACsec, DC, Back-to-Front Airflow

Name: Juniper ACX5448-M-DC-AFI Router, 44x 10GE + 6x 100GE, MACsec, DC, Back-to-Front Airflow
Brand: Juniper
SKU: ACX5448-M-DC-AFI
Price: 47235.36 USD
Availability: InStock

$47,235.36List price: $64,889.00

Available direct from Juniper Ask us for current lead time

ConditionNew

WarrantyManufacturer

ShippingFree (US)

ReturnsRMA required · See policy

Juniper Care & licenses for this modelSee options ↓

DC-powered ACX5448 with 44 SFP+ MACsec ports and 6 QSFP28 ports, back-to-front airflow and basic L2 and IGP software.

SKU: ACX5448-M-DC-AFI Categories: Juniper, Routers

Support & Licensing for the ACX5448-M-DC-AFI

Juniper licenses the ACX5448-M-DC-AFI by feature tier (Advanced or Premium) and by blocks of capacity. Every feature runs without a license key, but Juniper's terms require a license for the features and capacity you use. Most buyers also add Juniper Care support. Not sure what you need? Call (984) 225-1600 or request a quote and we'll spec it with you.

1Juniper Care support recommended

A support contract from Juniper for the ACX5448-M-DC-AFI. Every level includes 24/7 tech support and software updates; they differ in how fast a failed part is replaced.

Core24/7 Juniper tech support (JTAC) and software updates. No hardware replacement.SVC-COR-ACX5448-M
$3,230 / yr
Core PlusCore, plus repair or replacement shipped within 10 business days of Juniper receiving the failed part.SVC-CP-ACX5448-M
$3,631 / yr
Next DayCore, plus a replacement part delivered the next business day (RMA issued by 3 p.m. local time).SVC-ND-ACX5448-M
$4,036 / yr
Same DayCore, plus a replacement part delivered within 4 hours, 24/7.SVC-SD-ACX5448-M
$6,455 / yr

More levels: onsite technician and 2-hour delivery

Next Day OnsiteNext Day delivery, plus a technician on site to install the replacement part.SVC-NDCE-ACX5448-M
$5,044 / yr
Same Day OnsiteSame Day delivery, plus a technician on site to install the replacement part.SVC-SDCE-ACX5448-M
$8,070 / yr
Same Day 2-HourCore, plus a replacement part delivered within 2 hours, 24/7.SVC-SD2-ACX5448-M
$8,392 / yr

Delivery times depend on your location. Onsite technicians handle hardware replacement; software questions go to JTAC.

2Software license optional

Sold per block of capacity: buy enough blocks to cover the bandwidth you use on the ACX5448-M-DC-AFI. Tell us your port plan and we'll size it. Licenses are per router.

Advanced

For metro services over MPLS or segment routing:

Layer 2 features: LAG, MC-LAG, Q-in-Q, VXLAN, IRB, Ethernet OAM
Layer 2 VPN (pseudowire, VPLS, EVPN) and Layer 3 VPN
All IPv4/IPv6 routing protocols: OSPF, BGP, IS-IS, LDP
Segment routing, SR-TE and SRv6
Timing (PTP, SyncE), H-QoS and traffic filters
Telemetry, RFC 2544, LFM and CFM
Up to 32 L3 VPNs and 8 NG-MVPNs

Per 400G of capacity

Subscription Includes Juniper software supportS-ACX-400G-A-1/3/5

1 yr$3,815 3 yr$7,656$2,552 / yr 5 yr$11,485$2,297 / yr

Perpetual One-time purchase, without software supportS-ACX-400G-A1-P

Perpetual$8,581

Premium

For the metro and service edge. Everything in Advanced, plus:

Pseudowire headend termination (PWHT)
Every other feature that doesn't need its own license
Full platform scale for FIB and VPNs

Per 400G of capacity

Subscription Includes Juniper software supportS-ACX-400G-P-1/3/5

1 yr$5,801 3 yr$11,601$3,867 / yr 5 yr$17,402$3,480 / yr

Perpetual One-time purchase, without software supportS-ACX-400G-P1-P

Perpetual$12,876

3Add-on licenses only if you need them

Juniper's older ACX5000 licensing, still sold for this model: the right to use a set number of ports or a feature set.

10GbE port licensesThe right to use a set number of 10GbE ports.
- 1 × 10GbEACX5K-L-1X10GE-S
  Perpetual$1,750
- 8 × 10GbEACX5K-L-8X10GE-S
  Perpetual$13,511
- 16 × 10GbEACX5K-L-16X10GE-S
  Perpetual$27,018
- 24 × 10GbEACX5K-L-24X10GE-S
  Perpetual$40,449
- 48 × 10GbEACX5K-L-48X10GE-S
  Perpetual$80,902
100GbE port licenseThe right to use one 40GbE or 100GbE port.ACX5K-L-100GE-S
Perpetual$12,636
Layer 2 feature licenseLayer 2 features and IGP routing protocols, without MPLS or BGP, for network management only.ACX5K-L-L2
Perpetual$875
IP/MPLS feature licenseIP/MPLS features, except IP VPN.ACX5K-L-IP-MPLS
Perpetual$8,426
IP VPN feature licenseThe right to use IP VPN.ACX5K-L-IPVPN
Perpetual$4,211
Scale licenseMore than 256K FIB routes and more than 512 VRFs, up to the hardware limits.ACX5448-L-PE
Perpetual$12,636

Description

About the ACX5448-M-DC-AFI

The ACX5448-M-DC-AFI is the MACsec model for DC sites. It has 44 SFP+ ports and 6 QSFP28 ports, and two JPSU-850W-DC-AFI supplies run 1+1 at up to 550 W, with redundant fans.

Air enters at the power-supply side and leaves at the port side. Basic L2 and IGP are included; a software subscription is a separate order in Support & Licensing above.

What’s included

ACX5448-M router with 44 SFP+ and 6 QSFP28 ports, MACsec, DC power and back-to-front airflow
Redundant fans
Redundant DC power supplies
Junos OS with basic L2 software and IGP, without MPLS

Sold separately

Software subscription, listed in Support & Licensing above
Advanced and Premium licenses and Juniper Care, listed in Support & Licensing above

Choosing a version

ACX5448-M-DC-AFI (this page): DC power, back-to-front airflow
ACX5448-M-AC-AFI: AC power, back-to-front airflow
ACX5448-M-AC-AFO: AC power, front-to-back airflow
ACX5448-M-DC-AFI-L: Limited JUNOS, DC power, back-to-front airflow
ACX5448-M-DC-AFO: DC power, front-to-back airflow
ACX5448-M-DC-AFO-L: Limited JUNOS, DC power, front-to-back airflow

Related models: ACX5448-A-AC-AFO, ACX5448-D-AC-AFI.

Not sure which version you need? Call (984) 225-1600 or request a quote and we’ll check it against your rack and network.

ACX5448-M-DC-AFI specifications

Network ports	44x SFP+, 6x QSFP28
MACsec	Yes
Throughput	800 Gbps
Form factor	1U, fixed chassis
Dimensions (H x W x D)	1.7 x 17.26 x 24 in (4.3 x 43.8 x 61 cm)
Weight (as shipped)	19.73 lb / 8.95 kg
Airflow	Back-to-front
Power supplies	2x JPSU-850W-DC-AFI (1+1 redundant, hot-swappable)
Max power draw (DC)	550 W
Fans	6x ACX5448-D-FAN-AFI (hot-swappable)
CPU	1.9-Ghz six-core Intel
Memory	32 GB
Storage	200 (100+100) GB SSD
Operating temperature	32° through 104° F / 0° through 40° C
Operating system	Junos OS

Full specifications (44)

Network ports

SFP+ Ports	44
SFP+ Port MACsec	Yes
QSFP28 Ports	6
QSFP28 Port Channelization	Yes

Management and other ports

Console Ports	1
Console Port Type	RJ-45
Management Ports	1
Management Port Type	RJ-45
USB Ports	1
USB Port Type	Type A
10 MHz Port	Yes
PPS Port	Yes

Chassis

Chassis type	Fixed
Form Factor	1U
Chassis Height	1.7 in / 4.318 cm
Chassis Width	17.26 in / 43.8404 cm
Chassis Depth	24 in / 60.96 cm
Chassis depth (with power supplies and fans)	25.5 in / 64.77 cm
Weight (as shipped)	19.73 lb / 8.95 kg
Weight (fully loaded)	26.12 lb / 11.85 kg
Chassis Model Number	ACX5448-M-CHASSIS

Power

Power supplies	2
Power supply redundancy	1+1
Power supply airflow	Back-to-front
Hot-swappable power supplies	Yes
DC power supply model	JPSU-850W-DC-AFI
DC Max Power Consumption	550 W
DC Average Power Consumption	300 W

Cooling

Airflow Direction	Back-to-front
Fan module model	ACX5448-D-FAN-AFI
Fan modules	6
Hot-swappable fans	Yes

Processor

CPU	1.9-Ghz six-core Intel
Memory (DRAM)	32 GB

Storage

Internal Storage Size	200 (100+100) GB
Internal Storage Type	SSD

Switching and routing scale

Throughput	800 Gbps

Environmental

Operating Temperature	32° through 104° F / 0° through 40° C
Storage Temperature	-40° through 158° F / -40° through 70° C
Operating Altitude	6000 ft / 1829 m
Humidity, operating (noncondensing)	5% through 90%
Seismic Tolerance	Zone 4
Maintenance Clearance	24 in / 60.96 cm

Software

Operating system	Junos OS

Common questions

Is there a DC M model without the L suffix?

Yes: this one and the ACX5448-M-DC-AFO. The -L versions are different bundles with Limited JUNOS.

What power rating applies?

The maximum DC draw is 550 W, fed through two JPSU-850W-DC-AFI supplies.

Does this M model include MPLS or BGP?

No. It is basic L2 and IGP only, so MPLS and BGP need rights beyond the included software.
