Meraki MR36-HW Wi-Fi 6 Indoor Access Point – 2×2, 1G Uplink

Name: Meraki MR36-HW Wi-Fi 6 Indoor Access Point – 2x2
Brand: Meraki
SKU: MR36-HW
Price: 440.00 USD
Availability: InStock

$440.00List price: $946.31

In stock (10+) Ships today if ordered by 3 PM ET

ConditionNew

Warranty90 days

ShippingFree (US)

ReturnsRMA required · See policy

SKU: MR36-HW Categories: Meraki, Access Points

Description

About the MR36-HW

Two spatial streams and a gigabit uplink define the MR36-HW, an 802.11ax (Wi-Fi 6) indoor access point with 2×2 MIMO and internal antennas. Its aggregate frame rate is 1.5 Gbps, and it is managed from the Meraki Dashboard.

It draws 15 W max on 802.3af PoE, so it does not need PoE+. Where there is no PoE, a MA-INJ-4 or MA-INJ-6 injector powers it, or the 12 V DC input runs from the MA-PWR-30W-US adapter. The uplink is one 10/100/1000 RJ45 port.

Standard mounting hardware comes in the box for desk, wall and ceiling mounting, including flush or recessed ceiling tile rails. The MA-MNT-MR-17 mount also fits the MR36-HW.

What’s included

MR36-HW access point, managed from the Meraki Dashboard
Standard mounting hardware for desk, wall and ceiling mounting

Sold separately

A PoE injector (MA-INJ-4 or MA-INJ-6) or the MA-PWR-30W-US DC adapter where the switch port has no PoE

Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.

MR36-HW specifications

Wi-Fi standard	802.11ax (Wi-Fi 6)
Radios / spatial streams	2x2 MIMO, two spatial streams
Max data rate	1.5 Gbps aggregate frame rate
Uplink port	1× 10/100/1000 RJ45
Power (PoE class)	802.3af PoE (15 W max) or 12 V DC
Antennas (internal/external)	Internal
Indoor/outdoor	Indoor
Management	Meraki Dashboard

Full specifications (6)

Radio

Antenna gain	5.4 dBi at 2.4 GHz; 6 dBi at 5 GHz

Power and PoE

Power accessories	PoE injector and DC adapter sold separately

Physical

Mounting	All standard mounting hardware included; Desktop, ceiling, and wall mount capable; Ceiling tile rail (9/16, 15/16 or 1 1⁄2” flush or recessed rails), assorted cable junction boxes; Bubble level on mounting cradle for accurate horizontal wall mounting
Dimensions	9.84 × 4.72 × 1.42 in (25 × 12 × 3.6 cm)
Weight	17.35 oz (492 g)

Environment

Operating temperature	32 to 104°F (0 to 40°C)

Compatible parts

Power adapters
MA-PWR-30W-US	Output: 12V 2.5A DC	$32.15
PoE injectors
MA-INJ-4	802.3at PoE injector	$38.15
MA-INJ-6	Maximum output power: 60W	$219.99
Mounting kits
MA-MNT-CLG-1	T-rail mount kit	$13.30
MA-MNT-MR-17	Replacement mounting kit	$26.06
Mounting adapters
MA-UMNT-MR-A2	Adapter for Cisco universal mounting brackets	$15.96
MA-UMNT-MR-A3	Adapter for Aruba universal mounting brackets	$15.96
