About the C9200-24P-E
The C9200-24P-E is the 24-port PoE+ switch of the modular Catalyst 9200 line: 24 copper ports at up to 1G, all with full PoE+, in a 1U switch running Cisco IOS XE with the Network Essentials software tier. The C9200-24P-A is the same switch with Network Advantage, and the C9200-24PXG-E makes eight of the 24 ports multigigabit, up to 10G.
PoE depends on the power supplies. The included PWR-C6-600WAC gives a 370 W budget. The switch takes two field-replaceable supplies, and with two the budget goes up to 740 W, with power redundancy as well. For DC power, one PWR-C6-715WDC gives 485 W.
Uplinks come from a network module, and none is included: four 1G ports or four 1G/10G ports. Up to 8 C9200 switches stack over StackWise-160 at 160 Gbps with the stack kit.
What’s included
- C9200-24P-E switch with 24 PoE+ ports and the Network Essentials software tier
- 600 W AC power supply (PWR-C6-600WAC)
Sold separately
- A network module for uplinks: the C9200-NM-4G= (4× 1G) or the C9200-NM-4X (4× 1G/10G)
- A second 600 W supply, the PWR-C6-600WAC or PWR-C5-600WAC, for redundancy and up to 740 W of PoE
- The C9200-STACK-KIT and a STACK-T4-50CM, STACK-T4-1M or STACK-T4-3M cable if you stack it
Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.
C9200-24P-E specifications
| Downlink ports | 24× 10/100/1000 PoE+ (full PoE+) |
|---|---|
| Uplink ports | Modular: choose a network module (C9200-NM-4G 4× 1G or C9200-NM-4X 4× 1G/10G) |
| PoE budget | 370 W with 1× PWR-C6-600WAC (default); 485 W with 1× PWR-C6-715WDC= (spare-order DC option); up to 740 W with two power supplies |
| Stacking | StackWise-160, 160 Gbps; up to 8 members (C9200 only); stack kit sold separately |
| Switching capacity | 128 Gbps |
| Forwarding rate | 95.23 Mpps |
| Power supply | 600 W AC PWR-C6-600WAC included; dual field-replaceable supplies supported |
| Form factor | 1U rack-mount; 1.73 × 17.5 × 15.4 in (4.4 × 44.5 × 39.1 cm) (H × W × D) with power supply and fans |
| Management | Cisco IOS XE (CLI, WebUI) |
| Feature tier | Network Essentials |
| Dimensions | 1.73 × 17.5 × 13.8 in (4.4 × 44.5 × 35.0 cm) |
| Weight | 12.12 lb (5.5 kg) |
Other versions of this model
- C9200-24P-A Network Advantage$2,785.00 · In stock
Compare Catalyst 9200 models
Swipe the table sideways to see every column.
| Model | Ports | PoE budget | Price |
|---|---|---|---|
| C9200-24P-E this page | 24× 10/100/1000 PoE+ (full PoE+) | 370 W | $3,150.00 · In stock |
| C9200-24PXG-E | 24× PoE+: 8× multigigabit (up to 10G) + 16× up to 1G | 370 W | $4,400.00 · In stock |
| C9200-24T-E | 24× 10/100/1000, data only | None | $2,295.00 · In stock |
| C9200-48P-E | 48× 10/100/1000 PoE+ (full PoE+) | 740 W | $3,250.00 |
| C9200-48PXG-E-WS | 48× PoE+: 8× multigigabit (up to 10G) + 40× up to 1G | 740 W | $3,833.47 |
| C9200-48T-E | 48× 10/100/1000, data only | None | $2,950.00 · In stock |
| C9200-48PL-E | 48× 10/100/1000, partial PoE+ | 370 W | Ask for a quote |
Compatible parts
| Network modules | ||
|---|---|---|
| C9200-NM-4G= | 4× 1G | $399.57 · In stock |
| C9200-NM-4X | 4× 1G/10G | $745.21 · In stock |
| Power supplies | ||
| PWR-C5-600WAC | 600 W AC power supply | $1,205.75 |
| PWR-C6-600WAC | 600 W AC power supply | $815.00 · In stock |
| PWR-C6-715WDC | 715 W DC power supply | $1,148.61 |
| Stack kits | ||
| C9200-STACK-KIT | StackWise-160, 160 Gbps | $495.00 · In stock |
| Stack cables | ||
| STACK-T4-50CM | Data stack cable, 50 cm | $57.43 |
| STACK-T4-1M | Data stack cable, 1 m | $114.86 |
| STACK-T4-3M | Data stack cable, 3 m | $172.29 |
| Fans | ||
| FAN-T2= | Fan | Ask for a quote |
| Rack mount kits | ||
| REC-KIT-T1= | Recessed 1RU rack mount | Ask for a quote |
| Accessory | ||
| C9K-ACC-RBFT | Accessory | Ask for a quote |
| CAB-GUIDE-1RU | 1RU cable management guides | Ask for a quote |
| Blank module | ||
| C9200-NM-BLANK | Blank cover for the network module slot | Ask for a quote |
Common questions
Does the C9200-24P-E have uplink ports?
Not until you add a network module, which is sold separately. It takes the C9200-NM-4G= with four 1G ports or the C9200-NM-4X with four 1G/10G ports.
How much PoE does the C9200-24P-E deliver?
370 W on the included 600 W supply, and up to 740 W with two power supplies.
What is the difference between the C9200-24P-E and the C9200-24P-A?
The software tier. The -E runs Network Essentials and the -A runs Network Advantage; ports, PoE and stacking are the same.
