About the C9500-24Y4C-A
The C9500-24Y4C-A has 24 SFP28 downlink ports that run at 1G, 10G or 25G, and four 40G/100G QSFP28 uplinks built into the chassis. It runs Cisco IOS XE with Network Advantage, switches up to 2.0 Tbps and forwards up to 1 Bpps. It has no PoE.
Table sizes depend on the selected ASIC template: up to 82,000 MAC addresses and up to 256,000 IPv4 or IPv6 routes. It has 16 GB of DRAM and 16 GB of flash, and takes a pluggable SSD (240 GB, 480 GB or 960 GB) for added storage.
Two switches can work as one through Cisco StackWise Virtual over their data ports; there are no stacking ports. One power supply is included, and a second power supply gives 1+1 redundancy.
What’s included
- C9500-24Y4C-A switch with 24 SFP28 ports, four QSFP28 uplinks and the Network Advantage software tier
- One power supply
Sold separately
- A second power supply for 1+1 redundancy: C9K-PWR-650WAC-R, C9K-PWR-650WACL-R or C9K-PWR-930WDC-R
- Pluggable SSD storage, such as the C9K-F1-SSD-240G; all sizes are under Compatible parts below
- Four-point mounting rails, the C9500-4PTH-KIT
Not sure which model fits? Call (984) 225-1600 or request a quote and we’ll answer the same business day.
C9500-24Y4C-A specifications
| Downlink ports | 24× 1G/10G/25G SFP28 |
|---|---|
| Uplink ports | 4× 40G/100G QSFP28 (fixed) |
| PoE budget | None (no PoE) |
| Stacking | No stacking ports; Cisco StackWise Virtual (two switches joined as one over data ports) |
| Switching capacity | Up to 2.0 Tbps |
| Forwarding rate | Up to 1 Bpps |
| Power supply | Dual 1+1 redundant, one included; options: C9K-PWR-650WAC-R, C9K-PWR-650WACL-R, C9K-PWR-930WDC-R |
| Form factor | 1U rack-mount; 1.73 × 17.5 × 18.0 in. (4.39 × 44.45 × 45.72 cm) |
| Management | Cisco IOS XE (CLI, WebUI) |
| Feature tier | Network Advantage |
Full specifications (5)
Scale
| MAC addresses | Up to 82,000 (varies with the selected ASIC template) |
|---|---|
| IPv4 routes | Up to 256,000 (indirect + direct); up to 90,000 host/ARP (varies with the selected ASIC template) |
| IPv6 routes | Up to 256,000 (indirect + direct); up to 90,000 host (varies with the selected ASIC template) |
| VLAN IDs | 4,094 |
| DRAM / flash | 16 GB / 16 GB |
Other versions of this model
- C9500-24Y4C-E Network Essentials$14,363.59
Compare Catalyst 9500 models
Swipe the table sideways to see every column.
| Model | Ports | Uplinks | Price |
|---|---|---|---|
| C9500-24Y4C-A this page | 24× 1G/10G/25G SFP28 | 4× 40G/100G QSFP28 | $9,747.61 · In stock |
| C9500-16X-A | 16× 1G/10G SFP/SFP+ | Optional network module: 8× 1G/10G SFP+ (C9500-NM-8X) or 2× 40G QSFP+ (C9500-NM-2Q) | $7,025.99 · In stock |
| C9500-32C-A | 32× 40G/100G QSFP28 | None separate: all 32 ports are 40G/100G QSFP28 | $21,542.16 |
| C9500-32QC-A | 32× 40G QSFP+ | None separate: all 32 ports are 40G QSFP+ (16 can run 100G) | $19,883.08 |
| C9500-48Y4C-A | 48× 1G/10G/25G SFP28 | 4× 40G/100G QSFP28 | $12,500.00 · In stock |
Compatible parts
| Power supplies | ||
|---|---|---|
| C9K-PWR-650WAC-R | 650 W AC power supply, 20 ms hold-up | $1,375.00 · In stock |
| C9K-PWR-650WACL-R | 650 W AC power supply, 12 ms hold-up | $1,060.58 |
| C9K-PWR-930WDC-R | 930 W DC power supply | $1,061.31 |
| Fans | ||
| C9K-T1-FANTRAY | Fan tray, up to 4 fans | Ask for a quote |
| Rack mount kits | ||
| C9500-4PTH-KIT | Extension rails and brackets for four-point mounting | $25.27 |
| C9500-ACCKITH-19I | 19-inch rack mount accessory kit | $25.27 |
| C9500-ACCKITH-23I | 23-inch rack mount accessory kit | $25.27 |
| Storage | ||
| C9K-F1-SSD-240G | 240 GB pluggable SSD storage | $1,936.66 |
| C9K-F1-SSD-480G | 480 GB pluggable SSD storage | $2,646.77 |
| C9K-F1-SSD-960G | 960 GB pluggable SSD storage | $4,841.66 |
Common questions
What is the difference between the C9K-PWR-650WAC-R and C9K-PWR-650WACL-R?
Both are 650 W AC supplies. The C9K-PWR-650WAC-R has a 20 ms hold-up, the C9K-PWR-650WACL-R 12 ms. The C9K-PWR-930WDC-R is the 930 W DC option.
Can the 25G ports run at 10G?
Yes. Each SFP28 port runs at 1G, 10G or 25G.
