Cisco IEM-3400-8P – Rugged Series Advanced – Expansion Module – Gigabit Ethernet (PoE+) x 8

Name: Cisco IEM-3400-8P Rugged Series Expansion Module Gigabit PoE+
Brand: Cisco
SKU: IEM-3400-8P
Price: 4400.00 USD
Availability: InStock

Original price was: $7,363.46.Current price is: $4,400.00.

In stock (1) Ships today if ordered by 3 PM ET

ConditionNew

Warranty90 days

ShippingFree (US)

ReturnsRMA required · See policy

SKU: IEM-3400-8P Categories: Cisco, Industrial, Network Modules

Description

The Cisco IEM-3400-8P is a compact and rugged industrial Ethernet module designed to provide reliable and high-performance connectivity for industrial applications. It offers advanced features, Power over Ethernet (PoE) capabilities, and a flexible modular design.

The IEM-3400-8P module features eight 10/100BASE-TX Fast Ethernet ports, providing reliable and high-speed connectivity for industrial devices. These ports support PoE functionality, allowing for both data and power transmission to PoE-enabled devices such as IP cameras, wireless access points, and industrial sensors.

The module is designed to withstand harsh environmental conditions commonly found in industrial settings. It features a ruggedized enclosure with certifications for shock, vibration, and temperature resistance, ensuring reliable operation even in challenging environments.

Overall, the Cisco IEM-3400-8P module is a reliable and ruggedized solution for industrial networking deployments. Its compact size, advanced switching capabilities, PoE support, and industrial certifications make it an ideal choice for industrial environments where reliable and secure connectivity is essential, particularly when integrated with modular platforms.

MAIN SPECIFICATIONS

Product Description	Cisco Catalyst IE3400 Rugged Series Advanced Expansion Module – expansion module – Gigabit Ethernet (PoE+) x 8
Device Type	Expansion module
Form Factor	DIN rail mountable
Ports	Gigabit Ethernet (PoE+) x 8
Dimensions (WxDxH)	2.4 in x 5.3 in x 6 in
Weight	31.99 oz
Cabling Type	Ethernet 1000Base-T
Data Link Protocol	GigE
Capacity	IGMP groups: 1000 ¦ VLAN IDs: 256 ¦ Spanning Tree Protocol instances: 128 ¦ ACL: 1500
MAC Address Table Size	8000 entries
Network / Transport Protocol	TCP/IP, UDP/IP, NTP, ARP, FTP, BOOTP, DHCP, HTTP
RAM	4 GB
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 1588v2
Power	DC 9.6 – 60 V

EXTENDED SPECIFICATIONS

General

Device Type	Expansion module
Form Factor	DIN rail mountable

Networking

Ports	Gigabit Ethernet (PoE+) x 8
Connectivity Technology	Wired
Cabling Type	Ethernet 1000Base-T
Data Link Protocol	Gigabit Ethernet
Capacity	IGMP groups: 1000 ¦ VLAN IDs: 256 ¦ Spanning Tree Protocol instances: 128 ¦ ACL: 1500
MAC Address Table Size	8000 entries
Network / Transport Protocol	TCP/IP, UDP/IP, NTP, ARP, FTP, BOOTP, DHCP, HTTP
Remote Management Protocol	SNMP 1, SNMP 2, SNMP, RMON, Telnet, SNMP 3, HTTP, TFTP, SSH, SCP, NETCONF, RESTCONF, NTP, ICMP, DHCP, RSTP, YANG, TACACS+, RADIUS
Features	IGMP snooping, DiffServ support, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Quality of Service (QoS), DHCP server, Per-VLAN Spanning Tree Plus (PVST+), Uni-Directional Link Detection (UDLD), LACP support, LLDP support, DHCP relay, Port Security, Remote Switch Port Analyzer (RSPAN), Management Information Base (MIB), dynamic ARP protection, static routing, Flexible NetFlow (FNF), Precision Time Protocol (PTP), IGMP filtering, IP source guard, Resilient Ethernet Protocol (REP), SmartPort technology, IGMP querier, Voice VLAN, Guest VLAN, Switched Port Analyzer (SPAN), VLAN Trunking Protocol (VTP) v.3, BPDU Guard, 802.1x filtering, VLAN Trunking Protocol (VTP) v.2, EtherChannel support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 1588v2

Processor / Memory

RAM	4 GB
Flash Memory	1.5 GB
Supported Memory Cards	SD Memory Card

Expansion / Connectivity

Interfaces

8 x 1000Base-T (PoE+) – RJ-45

Miscellaneous

MTBF

1,802,010 hours

Compliant Standards

CISPR 24, EN55024, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-8, IEC 60950-1, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, EN 61326-1, EN 61000-4-16, EN 61000-4-29, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IP30, VCCI Class A, CISPR 11 class A, EN 61000-4-10, EN 61000-4-18, IEC 61850-3, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, EN 300 386, KN35, UL/CSA60950-1, AS/NZS CISPR 32 Class A, KN32 Class A, IEC 62368-1, EN 55032, EN 60068-2-52, EN 60068-2-60, CISPR 32 Class A, UL 62368-1, EN 60079-15, CB 60950-1, IEC 60079-0, IEC 60079-15, EN 60079-0, EN 61000-4-17, CAN/CSA C22.2 No. 213, UL 121201, EN 61850-3, UL/CSA 61010-2-201, IEC/EN 61010-2-201, UL/CSA 60079-0, UL/CSA 60079-15, CSA 62368-1, CB 62368-1

Power
